DJI Mini 4 Pro specifications including battery leaked online

This morning, Igor Bogdanov, aka Quadro_News, shared the following Pro specifications, including the battery specs online and photos. Let's take a closer look.

It seems that the information below has either been derived from an image or pdf or may even have been translated, as there were a few inconsistencies in the text. However, we do believe this information to be highly accurate.

DJI Mini 4 Pro Camera Specifications

Image sensor: 1/1,3 inch CMOS, effective pixels: 48 MPX

Lens

  • FOV: of 82.1°
  • Format equivalent: 24 mm
  • Aperture: f/1.7
  • Focus: 1 m to o

ISO Range Video

  • Normal and Slow Motion:
  • 100-6400 (Normal)
  • 100-1600 (D-Log M)
  • 100-1600 (HLG)

Night:

  • 100-12800 (Normal)

Photos

  • 12 MP: 100-6400
  • 48 MP: 100-3200

Shutter Speed

  • 12MP Photos: 1/16000-2 (2.5-8 with for a simulated long exposure)
  • 48MP photos: 1/8000-2 with…

Max. image size: 8064×6048

Shooting modes:

  • One shot: 12 MP and 48 MP
  • Sequential shooting mode: 12 MP, 3/5/7 frames or 48 MP, 3 images

Automatic exposure series (AEB):

  • 12 MP, 3/5/7 frames with steps down 0.7 EV
  • 48 MP, 3 pictures with steps down 0.7 EV

Timer:

  • 12 MP, 2/3/5/7/10/15/20/30/60 with
  • 48 MP, 5/7/10/15/20/30/60 with

Photo format: JPEG/DNG (RAW)

Video resolution:

  • H.264/H.265
  • 4K: 3840×2160 @24/25/30/48/50/60/100fps
  • FHD: 1920×1080 @24/25/30/48/50/60/100/200*fps
  • The frame rate of the recording. The relevant video is played back as a slow-motion video. 4K/100 fps and HLG/D-Log M only support encoding
    H.265.

Video format:

  • MP4 (MPEG-4 AVC/H.264, HEVC/H.265)

Max. video bitrate:

  • H.264/H.265: 150 Mbps supported file system

Color mode and sampling method

  • Normal:
    8-bit 4:2:0 (H.264/H.265)
    HLG/D-Log M:
    10-bit 4:2:0 (H.265)
  • Digital zoom
    12MP photos: 1-2x
    4K: 1-3x
    FHD: 1-4x

DJI Mini 4 Pro Battery

Compatible battery: DJI Mini 4 Pro Intelligent Flight Battery, Series Intelligent Flight Battery Plus. Intelligent Flight Battery Plus is not in in the sale.

Capacity: Intelligent Flight Battery: 2590 mAh

Weight: Intelligent Flight Battery: about of 77.9 grams

Nominal voltage: Intelligent Flight Battery: 7,32 In

Max. charging voltage: Intelligent Flight Battery: 8,6 In

Type: Li-ion

The temperature of the charging: 5 °C to 40 °C (41 °F to 104 °F)

Time of charging the Intelligent Flight Battery:

  • 70 minutes (with DJI 30W USB-C Charger and battery pack placed in the drone)
  • 58 minutes (with DJI 30W USB-C Charger and the battery inserted into the Two-Way Charging Hub
DJI Mini 4 Pro specifications including battery leaked online

" data-image-caption="

DJI Mini 4 Pro specifications including battery leaked online

" data-medium-file="https://dronexl.co/wp-content/uploads/2023/09/DJI-Mini-4-Pro-specifications-including-battery-leaked-online-2-1000x642.jpg" data-large-file="https://dronexl.co/wp-content/uploads/2023/09/DJI-Mini-4-Pro-specifications-including-battery-leaked-online-2-2000x1285.jpg" src="https://dronexl.co/wp-content/uploads/2023/09/DJI-Mini-4-Pro-specifications-including-battery-leaked-online-2-2000x1285.jpg" alt="DJI Mini 4 Pro specifications including battery leaked online" class="wp-image-35940" title="DJI Mini 4 Pro specifications including battery leaked online 2" srcset="https://dronexl.co/wp-content/uploads/2023/09/DJI-Mini-4-Pro-specifications-including-battery-leaked-online-2-2000x1285.jpg 2000w, https://dronexl.co/wp-content/uploads/2023/09/DJI-Mini-4-Pro-specifications-including-battery-leaked-online-2-1000x642.jpg 1000w, https://dronexl.co/wp-content/uploads/2023/09/DJI-Mini-4-Pro-specifications-including-battery-leaked-online-2-768x493.jpg 768w, https://dronexl.co/wp-content/uploads/2023/09/DJI-Mini-4-Pro-specifications-including-battery-leaked-online-2-1536x987.jpg 1536w, https://dronexl.co/wp-content/uploads/2023/09/DJI-Mini-4-Pro-specifications-including-battery-leaked-online-2-scaled.jpg 2048w, https://dronexl.co/wp-content/uploads/2023/09/DJI-Mini-4-Pro-specifications-including-battery-leaked-online-2-150x96.jpg 150w" sizes="(max-width: 2000px) 100vw, 2000px">
DJI Mini 4 Pro mid-flight and controlled by somebody using the DJI RC-N2 remote controller.

DJI Mini 4 Pro Video Transmission

The Transmission System Videos: 04

The quality of the live view Remote controller:

  • Up to 1080p/60 fps available when the drone is flying in the regime of Photo or Video)
  • Up to 1080p/30 fps (available when the drone flies in Video mode)
  • Up to 1080p/24fps (available when the drone is in the standby mode on the ground)

Operating frequency:

  • 2.4000-2.4835 GHz
  • 5.170-5.250 GHz
  • 5.725-5.850 GHz
  • 5,170-5,250 GHz may only be used in and areas where it is permitted by local laws and regulations

Max. transmission distance (unobstructed, with interference)

  • Strong interference: the city, about 1.5-4 km
  • High interference: the suburban landscape, approximately 4-10 km
  • Low interference: the suburbs/the coast, approximately 10-20 km

Low interference and obstacle in the form of trees:

  • approximately 0.5 – 3 km

Max. the speed of downloading 04:

  • 10 MB/s (with DJI RC-N2)
  • 10 MB/s (with DJI RC 2)
  • Wi-Fi 5: 30 MB/s*

Lowest latency

Drone + Remote control: approximately 120 ms. Depending on the current environment and mobile device.

Antenna:

4 antennas, 2T4R

Transmitter power (EIRP):

  • 2.4 GHz:
    < 33 dBm (FCC)
    < 20 dBm (CE/SRRC/MIC)
  • 5.1 GHz:
    < 23 dBm (CE)
  • 5.8 GHz:
    ‹ 33 dBm (FCC)
    ‹ 30 dBm (SRRC)
    < 14 dBm (CE)

Max. transmission distance (unobstructed, free of interference)

  • FCC: 20 km
  • CE: 10 km
  • SRRC: 10 km
  • MIC: 10 km

DJI Mini 4 Pro Obstacle Avoidance System

Scan type: Omnidirectional binocular camera system complete with 3D infrared sensor at the bottom of the drone.

Front

  • Measuring range: 0,5 – 18 m
  • Detection range: 0,5 – 200 m
  • Effective scan speed: Flight speed ≤ 12 m/s
  • FOV: Horizontal 90°, Vertical 72°

Back

  • Measuring range: 0.5 to 15 m
  • Effective scan speed: Flight speed ≤ 12 m/s
  • FOV: Horizontal 90°, Vertical 72°

Side

  • Measuring range: 0,5 – 12 m
  • Effective scanning speed: flight Speed ≤ 12 m/s
  • FOV: Horizontal 90°, Vertical 72°

Top

  • Measuring range: 0,5 -15 m
  • Effective scanning speed: flight Speed ≤ 5 m/s
  • FOV: Front and rear 72°, Left and right 90°

Bottom

  • Measuring range: 0.3 to 12 m
  • Effective scanning speed: flight Speed ≤ 5 m/s
  • FOV: Front and rear 106°, Left and right 90°

Operating environment:

  • Front, rear, left, right and top
  • Surfaces with discernable patterns and adequate lighting (lux > 15).

Bottom:

  • Surfaces with discernable patterns, diffuse reflectivity > 20 percent (such a walls, trees, people) and adequate lighting (lux > 15).

3D infrared sensor

  • Measuring range: 0,1 – 8 m (reflectivity > 10 %)
  • FOV: Front and rear 60°, left and right 60°
